3D printing drives significant cost savings compared to traditional manufacturing, dramatically advancing speed, performance, and customization of competitive racing sleds

Team USA collaborates with Stratasys to power design and development of complex, composite layup and sacrificial tooling – enabling sled track speeds of nearly 90 miles per hour

Minneapolis & Rehovot, Israel, February 13, 2018 – Advancing its winning track-record as a global leader in applied additive technology solutions, Stratasys (NASDAQ: SSYS) today announced the company has teamed with USA Luge to inject additive manufacturing into its quest for gold in Pyeongchang, South Korea this month. Harnessing the power of Stratasys Fused Deposition Modeling (FDM) 3D printing technology, the luge team is now able to more rapidly and cost-effectively build and test customized racing sleds tailored to the body of each athlete.

USA Luge is tapping into a wide range of high-performance materials from Stratasys to 3D print key layup and sacrificial tools used during manufacturing of carbon-fiber composite sleds. The advanced functionality of FDM enables an unprecedented level of customization not possible with standard composite fabrication – a critical success factor in racing sleds that often travel at speeds upwards of 87 miles per hour.

Additive manufacturing is key for engineering mandrels for the racing team’s Doubles Tower – a composite structure at the sled’s front, used to accurately position riders’ legs during competition. Extremely difficult to fabricate due to complex, trapped-tool geometry – the structure guarantees proper athlete fit and position while racing. Leveraging the Stratasys ST-130 sacrificial (wash-out) tooling material, team designers were able to 3D print the mandrel, layup and cure the composite structure, and wash-out the tooling material – all in less than one week.

“Competitive luge racing is an extremely demanding sport where fractions of a second are the difference between winning and losing. Our riders depend on comfortable, aerodynamic sled designs to win races,” said USA Luge Technical Programs Manager, Jon Owen. “In teaming with Stratasys, we’ve become much more competitive on the world stage – continuously adjusting designs and running them on the track much faster than traditional processes. Additionally, we’ve balanced both comfort and performance by tailoring the sled to each rider’s body, while minimizing fabrication cost and time.”

Based on the success of Doubles Tower construction, Team USA has pushed the technology even further by 3D printing the entire sled body layup tool. This particular design incorporates a removable middle section, allowing tool length to adjust based on each rider’s height. Driven by these efforts during prototyping, designers are currently using this same tooling for final sled components during competition.

“Stratasys customers push the limits of performance, efficiency, and reliability for 3D printed rapid tooling, prototypes and production parts. Partnering with USA Luge highlights a perfect example of an environment where our additive manufacturing technology enables customers to meet critical needs in specialized applications,” said Scott Sevcik, Vice President of Manufacturing Solutions at Stratasys. “We’re proud to partner with Team USA, one of the best teams in winter sports, to help them apply the power of FDM technology to keep moving faster, in the shop, and on the track.”

Competitive luge races in Pyeongchang are taking place February 10-15, with Stratasys-powered sleds leading the way. For more information on how Stratasys can accelerate your business and lean manufacturing strategies, please visit: http://www.stratasys.com/solutions/additive-manufacturing.
